SG60NC Tube End Forming Shrink Machine


The product is controlled by microcomputer and driven hydraulically. It applies Chinese character display and man-machine conversation operation, and can be operated manually or semi-automatically. One-point foot switch has two functions, startup and emergency stop.


  • Category: Tube End Forming Machine

Description

Tube End Forming Shrink Machine

Tube End Forming Shrink Machine

Feature:
1. With double-station arrangement, pipe finish forming machine will shrink the tube for 2 times at the same time. Applying linear guide way because the carrier, the merchandise will guarantee action while not abrasion and guarantee sensible repeat ability.
2. Processing shapes: convex-shaped, concavity-shaped, nodular form, long partial form, sq. form, topological form, oblique form, V-shape, cracking kind and flat kind. the form of the mould shall be subject to the article to be processed.

Specification/modelSG60NC
Input voltage380V±10%  50HZ Three-phase power (customizable)
Control circuit24V

Maximum forming pipe diameter x thickness

(Iron pipe)

Φ60*2mm
Maximum working process110mm
Oil pump23L
Motor power5.5kw
Hydraulic pressure12Mpa
Measurement size of machine 2000*660*1300mm
Weight of machine1200KG
